ROHS Gold/Nickel Plating 500 Rf Male Sma Rg58 Rg59 Coaxial Cable

FOB Reference Price:Get Latest Price
$0.30 - $1.20 / Pieces | 100 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 1 Negotiable
Customization:
Accoding Drawing Customized (Min. Order: 10 Pieces)
Samples - $1.20 /Pieces, 1 Pieces (Min. Order): Buy Samples
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
RCD
Model Number:
RCD0015
Number of Conductors:
1
Name::
Rf Male Sma Coax Cable
Connector::
SMA or OEM
Conductor Material::
100%Bare Copper
Jacket::
ROHS
Length::
10cm OEM
Color:
Black OEM
Cable:
RG Cable
Impedance::
50 Ohm
Warranty::
2 years
Packing::
PE bag
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month wires and cables
Packaging & Delivery
Packaging Details
As Client Request
ROHS Gold/Nickel Plating 500 Rf Male Sma Rg58 Rg59 Coaxial Cable
Port
Shanghai
Lead Time :
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 1 To be negotiated
Product Description



ROHS Gold/Nickel Plating 500 Rf Male Sma Rg58 Rg59 Coaxial Cable&nbsp

 RF coaxial cable assembly (7/16 DIN/N/TNC/BNC/FME/U.FL/IPEX/L9/SMA/SMB/MMCX/MCX/OEM) .
We focus on coaxial assemblies.
Our custom RF cable assemblies are built-in and shipped worldwide.
RF cable assemblies in 50 ohms can be ordered using the following connector types such as 7/16 DIN, BNC, FME, MCX, MMCX, N, QMA, SMA, SMB, SMC, SMP, SSMB, TNC, UHF, U.FL and 75 ohms cable assemblies can be made with the following 75 ohms connectors such as BNC, F, N, SMB, SMC, TNC and mini SMB .
RF cable assemblies includes: RG141/RG142/RG174/ RG178/RG179/RG180/ RG187/RG196/RG213/RG214/RG218/RG219/ RG223/RG303/RG316/RG316-DS/RG393/RG400/RG401/RG402/RG405/RG58/U
 RF cable assemblies can be produced with many different connector types and custom lengths depending on your needs and applications.

If you require a special RF cable assembly configuration not found here, you can create your own RF cable assembly configuration by calling our sales department.



ELECTRICAL DATA
Impedance
50Ω
Frequency range
DC-6Ghz
VSWR
1.3 max
Voltage
60V AC(rms)
Insulation Resisitance
500 MΩ min.
Insertion Loss
0.3dB max. at 1.0 GHZ/0.5DB max. at 2.0 GHZ
MATERIAL DATA
Bodies
Brass--gold/Nickel plating
Pin contacts
Brass--gold plating
Socket contacts
Copper-beryllium alloy--Au plating
Insulator
PTFE
Cable type
0.81mm,1.13mm,1.37mm,RG178,RG174,RG316,RG58,LMR195,LMR240
Application
smartphone,tablet PC,wifi antenna,GPS antenna, RF device etc
Temperature range
-40°C to +80°C
