Fast Delivery Coaxial Cable RF Cable MMCX To SMA Pigtail 1.13 Cable.

FOB Reference Price:Get Latest Price
$0.65 - $1.20 / Pieces | 100 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 1 Negotiable
Customization:
Drawing Customized (Min. Order: 100 Pieces)
Samples - $1.20 /Pieces, 1 Pieces (Min. Order): Buy Samples
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
RCD Piatail Cable
Model Number:
MMCX TO SMA Pigtail Cable
Number of Conductors:
1
Name:
MMCX TO SMA Pigtail Cable
type:
RF CABLE PIGTAIL CABLE
Cable length:
OEM
VSWR::
1.3Max
Max inputer Power:
50W
Jacket:
PVC
Impedance::
50ohm
Service:
OEM.ODM
Certification:
CE/ROHS/ISO9001
Application:
smartphone,tablet PC,wifi antenna,GPS antenna, etc
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month wires and cables
Packaging & Delivery
Packaging Details
As Client Request
Fast Delivery Coaxial Cable RF Cable MMCX To SMA Pigtail 1.13 Cable.
Port
Shanghai
Lead Time :
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 1 To be negotiated
Product Description

Click botton   Contact Supplier  can be get free sample!!!

Fast Delivery Coaxial Cable RF Cable MMCX To SMA Pigtail 1.13 Cable

 RF coaxial cable assembly (7/16 DIN/N/TNC/BNC/FME/U.FL/IPEX/L9/SMA/SMB/MMCX/MCX/OEM) .
We focus on coaxial assemblies.
Our custom RF cable assemblies are built-in and shipped worldwide.
RF cable assemblies in 50 ohms can be ordered using the following connector types such as 7/16 DIN, BNC, FME, MCX, MMCX, N, QMA, SMA, SMB, SMC, SMP, SSMB, TNC, UHF, U.FL and 75 ohms cable assemblies can be made with the following 75 ohms connectors such as BNC, F, N, SMB, SMC, TNC and mini SMB .
RF cable assemblies includes: RG141/RG142/RG174/ RG178/RG179/RG180/ RG187/RG196/RG213/RG214/RG218/RG219/ RG223/RG303/RG316/RG316-DS/RG393/RG400/RG401/RG402/RG405/RG58/U
 RF cable assemblies can be produced with many different connector types and custom lengths depending on your needs and applications.

If you require a special RF cable assembly configuration not found here, you can create your own RF cable assembly configuration by calling our sales department.
ELECTRICAL DATA
Impedance50Ω
Frequency rangeDC-6Ghz
VSWR1.3 max
Voltage60V AC(rms)
Insulation Resisitance500 MΩ min.
Insertion Loss0.3dB max. at 1.0 GHZ/0.5DB max. at 2.0 GHZ
MATERIAL DATA
BodiesBrass--gold plating
Pin contactsBrass--gold plating
Socket contactsCopper-beryllium alloy--Au plating
InsulatorPTFE
Cable type0.81mm,1.13mm
Applicationsmartphone,tablet PC,wifi antenna,GPS antenna, etc
Temperature range-40°C  to +90°C
